Chevrolet Sonic: Exterior Lighting

Chevrolet Sonic Owners Manual


The exterior lamp control is on the instrument panel to the outboard side of the steering column.

O : Briefly turn to this position to turn the automatic light control off or on again.

AUTO: Turns the headlamps on automatically at normal brightness, together with the following:

  • Parking Lamps
  • Taillamps
  • License Plate Lamps
  • Instrument Panel Lights
  • Sidemarker Lamps

: Turns on the parking lamps including
all lamps except the headlamps.

: Turns the headlamps on together
with the parking lamps and instrument panel lights. A warning chime sounds if the driver door is opened when the ignition switch is off and the headlamps are on.

: For vehicles with fog lamps, press
to turn the lamps on or off. See:

  • Exterior Lamp Controls
  • Daytime Running Lamps (DRL)
  • Fog Lamps
