Fiat Punto: Door mirrors

Fiat Punto Owners Manual

Manual adjustment

From the passenger compartment, use knob (A) to make the required adjustments. When required (for example when the mirror causes difficulty in narrow spaces) it is possible to fold the mirror moving it from position (1) to position (2).

Manual adjustment


Electrical adjustment (where provided)

This operation can be only performed with ignition key to MAR.

Proceed as follows:

  • use switch (B) to select the mirror required (left or right);
  • to adjust the mirror move (A) in the four directions;

IMPORTANT Any adjustment of the mirror position must be carried out only with the car stationary and handbrake engaged.

Electrical adjustment


When driving the
mirrors shall always be in position (1).

As the driver’s door
mirror is curved, it may slightly alter the perception of distance.
    Driving mirror
