Fiat Punto: Symbols
Fiat Punto Owners Manual
Special coloured labels have been attached near or actually on some of the components of your Fiat Punto. These labels bear symbols that remind you of the precautions to be taken as regards that particular component.
The plate summarising the symbols used can be found under the bonnet.
